LS-30 with LS-32 flat mounting plate, custom dust washer and top cover

I’ve had a pair of these now rare Seimitsu LS-30 joysticks for a while, but haven’t bought any games to use them with yet. I didn’t like the state they were in when I got them and have been putting off fixing them up for the last few years since I bought them. But I recently acquired a pair of used top bits (the plastic top bit with the old Seimitsu logo) and decided to see if I can make the joystick itself any better.

The biggest flaw of the LS-30 in my opinion is that the throw is too long and it feels kinda “mushy”. This might be because I got my pair used, but I  remember this feeling from back when I was playing Heavy Barrel in the arcades in the 80′s, so maybe the compromise to get the rotary function working came with the price of the 8-way function of the stick taking the back seat.

First off, I wanted to compare the bits the joystick is built from with less rare joystick models, and I have a couple of spare bits that seemed to fit the bill. I had a Seimitsu LS-32 (not used any bits for my mod, but comparisons are below), some SANWA JLF parts (the metal washer is used, the shaft cover I didn’t use) and an Ultimarc Ultimate 360 Hard Spring that I picked up along with a SUZO 500 as I was curios if the spring would be of use in an arcade joystick. Seems I was right, as it’s very close in feel to the LS-30 spring (that’s actually even tougher, rivally the SUZO 500 spring). I did try some of the other springs I have here, like the LS-33, JLF and LS-32 one’s, but this had the perfect width and height also.

I also tried to fit the same type of microswitch used in LS-32 (I had brand new spares) but it was too loose compared to the ones fitted in my LS-30 (Matsushita brand if I recall correctly). I might pick up some SAIA BURGESS ones again with blades next time I order from Arcadeshop.de as they are the best blade fitted microswitches I’ve tried so far.

Yesterday, someone posted @ ArcadeOtaku that the LS-32 plates will fit the LS-30 (so that I can mount these with little to no hassle), with this in mind, I finally got one of these out of my storage and got to work making them decent.

LS-30 & LS-32 plastic bit comparison

LS-30 & LS-32 plastic bit comparison 2

Spring comparison - LS-30 and Ultimarc Ultimate360 "hard spring"

Shaft cover comparison

I didn’t have a drill at hand to make the SANWA JLF shaft cover fit the LS-30 shaft, but the outer diameter is spot on, so I might get a drill so I can use these. The taller JLF cover will compact the spring a bit more, but I don’t think it will be an issue as the spring still has some space to move about.

Putting the stick together again after pulling it apart involved lots of trial and error, especially as I was trying out lots of different parts from the LS-32 (nothing really worked well) but I finally got a result that feels really good. The spring was getting stuck a lot and the centering wasn’t consistent, so I tried lots of washers until it struck me that I did have some JLF parts. The JLF metal washer fit perfectly under the microswitches, stopping the shaft cover from going through the hole.

SANWA JLF metal washer

I installed everything in this order:

1. Install the SANWA washer (like pictured above)
2. Install the small plastic washer (same diameter as the shaft cover)
3. Install the microswitches
4. Install the metal bracked with 4 screws that hold the microswitches in place
5. Put the spring on the shaft against the e-clip that sits above the square rotary PCB at the bottom of the shaft
6. Install the LS-30 metal washer (this was placed where I put the SANWA JLF washer when I took this apart)
7. Install the bigger plastic washer with the “rim” pointing upwards
8. Put the shaft through the bottom of the joystick body
9. Install the shaft cover and press it down until you can install…
10. …the top e-clip

Now, the joystick should feel very nice and the bottom part will look like this:

Order of the parts

If you want to install it in a panel, no need to put the yellow handle on yet as it’ll be too big. Also, you can’t get a dustwasher on the shaft with the top e-clip on, I had just put my washer on to take a nice picture (custom washer courtesy of BlingStix):

Custom dust washer - same size as the ones that comes with JLF shaft covers

Finally, I noticed that the old top parts with the Seimitsu logo on reminded me of the face part of arcade pushbuttons in both shape and size, so I pulled some HAPP buttons out and disassembled it and what do you know, the size was perfect and the colour is really close!

Top part compared to HAPP arcade pushbutton

Then I test fitted it in the LS-30 top part:

Test fit is successful - LIKE A GLOVE!

Excited of this new find, I cut off the “prong” things from the button and got this result:

Brand new top replacement - on the cheap

This was a mistake sort of, as I now have to drill it to get it out without damaging my handle. *facepalm* But I was just that excited I guess. And the buttons are really cheap (I have more yellow ones just laying around) so it’s no big deal. The HAPP Competition buttons will probably look even better as they are the same shape of the LS-30 top, but I’m really happy with the results of this cheap solution, and unless you know how the original looks, you wouldn’t know.

I need to find some screws that fit the holes that hold the LS-32 plate though as only one of my sticks has the original LS-30 plate and the holes for them sit  just above the microswitches’ spades, but that’s about it. Next up is installing these in my 2 player panel and getting a rotary game to try, like the awesome Midnight Resistance.

I hope this helps for other owners of these sticks!
